RCS 4SKY

The RCS 4SKY is a cable-based camera system designed to capture large-scale scenes, making it perfect for stadiums, arenas, and event venues. Innovative features such as teleprompter support and two-way audio elevate the system’s versatility to a new level, ensuring no (sporting) highlight goes unnoticed

The camera system

The RCS 4SKY features a robust, water- and dust-resistant design, suitable for temperatures ranging from -20°C to +45°C. Thanks to its fiber optic technology, it ensures interference-free transmission. Ideal for all types of sporting events where spectacular images need to be captured

Specialties

The camera system’s flight speed ranges from 8 to 10 m/s and can be used in any weather conditions (-20°C to +45°C). It is compatible with all standard box cameras, making it particularly suitable for sporting events.

Technical specifications

Technical Specifications RCS 4SKY

– Maximum speed: 8 – 10 m/s
– Maximum airfield size of 180 m x 180 m (larger on request)
– Operating time per battery charge 3 – 4 hours
– Dolly weight of 15 kg
– Synthetic special ropes
– Certified according to DGUV 17 / 18 (BGVC1)

Technical data winch

– 24 V UPS units (communication guaranteed even in the event of a power failure)
– Size: 113 cm x 68.5 cm x 79 cm
– Area approx. 2 x 1 m, on level ground
– Weight: 200 kg/winch
– Maximum force exerted on the rope: 72 kg

Technical data pulley and dolly

– Back plate: 30 cm x 30 cm
– Pulley is movable in all axes
– Load capacity pulley: Up to 20kN
– Dolly weight: 15 kg
– Maximum camera weight: 8 kg
– Battery performance: 3 – 4 h

Downloads:

Dadasheet_4SKY
